W PAN Patio Cover Systems come with...
Instructions, fascia gutters for all four sides, 16" wide 'W' pans, corners, screws,
sealant and scuppers, beams and posts as necessary.
All quoted units are designed to meet 2011 IBC standards using live load ratings
of 20, 30, & 40 pounds per square foot (psf) and wind ratings of 90, 100, & 120
miles per hour (mph) respectively.
(20/90 , 30/100 , 40/120)
Simple span load table given below for your convenience
All front heights should be calculated on a specification of a ¼” drop per
foot of projection.
Both Wall attached and Free-standing systems available
Projection (pan direction) is indicated as the distance away from the house,
from the house wall to the front of the unit.
Width is the distance along the house wall that the unit is to span.
Your posts will need to be spaced according to the IBC standard determined
by the required load rating (see point #1).
You May Need...click here
3" x 16" W pan systems are available in .019, .025 and .032 gauge thicknesses. The thickness you require will be determined by the live load rating set out by your local building department. Click here for all you will need to get a quote from us...
Precision stamped fascia corners
Fascia gutters available in 7 colors
Factory painted columns and beams.
Pans available in white or ivory
Beams available in white or dark bronze
Downspouts are not included
.078 ga. Aluminum Posts available in white, ivory or dark bronze.
Designed and engineered for loading in your area.
Starting at under $1100 for smaller sizes.
Also available in 'free standing configurations.
Covers can be can be cut down to the exact size you need. Order a larger size than you need and cut it down as you build it.
All aluminum components ensure a rust free, long life!
How to read the table:
For example in the table below...
7'5" is how far you can go 'away from the wall' before the .019" thick pan needs to be supported under a 20lb. load requirement.
|16" x 3" W Roof Panel - Maximum Panel Simple Span
Our units are pre-engineered systems that have been approved by qualified, state approved engineers in 45 States. Our systems are rated according to 2011 International Building Codes. Snow drifting and wind uplift have not been considered in the wall attached units. If local specifications require such engineering, these standards can be met at an additional cost. Current approved standards assume an importance factor equal to 1 & wind exposure equal to "B". If you require documentation and registered engineering stamps we will submit your request with your quotation. We cannot talk to engineers about such items prior to knowing what it is you require.
